Product description

The electrolytic cell body is a bipolar filter press type plate and frame structure, adopts a

special sealing structure and materials, and has no leakage in long-term operation.The high

operating pressure of the device saves the investment in compressors and large-capacity

wet storage tanks.The load adaptability is strong, and the operating pressure and output are

continuously adjustable below the rated value.The current efficiency is high, and the energy

consumption is much lower than that of the atmospheric tank.Microprocessor control, automatic

operation, complete fault alarm protection function.All parts in contact with media are made

of high-quality stainless steel or nickel-plated on the surface to improve corrosion resistance.

Long lasting.It is small in size and light in weight. The whole set of generator is assembled with

an integrated frame structure, which is convenient for installation and transportation.Complete

supporting facilities and diverse options can help users obtain the best economical configuration.

Tech Specification

P/N	ZXD-5
Hydrogen Production（m3/h）	5
Oxygen Production（m3/h）	2.5
Hydrogen Purity（V/V）	≥99.99%
Oxygen Purity（V/V）	≥92.5%
Operating load	50%-100%
Working Pressure（MPa）	1.5~3.0
Hydrogen Moisture Content（g/m3）	≤4
Hydrogen Alkalinity（mg/m3）	≤1
Working Temperature（℃）	85±5
Cooling water flow（m3/h）	1.3
DC power consumption(kW·h/m3H2)	≤4.3
External dimension of electrolyzer L×W×H （mm）	940×850×780
Electrolyzer Weight（kg）	1300
Alkali concentration	30% KOH
Circulation quantity of alkali liquor（m3/h）	0.3~0.35
Koh consumption (normal operation)（kg/unit）	45
