Large size alkaline electrolyzer
$774.90
Product Specification
Email:sales2@zxdh2.com Skype: dddemi33
Whatsapp:+8618030235313 Manager: Tiffany
Main equipment composition: electrolytic cell
Auxiliary equipment composition: water tank, alkali tank, make-up water pump and gas decompression distribution frame, etc.
Composition of electric control equipment: rectifier cabinet, power distribution cabinet, etc.
The equipment can be customized for users. The electrolytic cell, gas-liquid treatment device and hydrogen drying frame are assembled into a frame, which covers a small area.
The product has high hydrogen purity and low moisture content. It has a high degree of automation, and fully realizes the automatic one button start-up and stop.
Technical features
| P/N | ZXD-10 |
|---|---|
| Hydrogen Production（m3/h） | 10 |
| Oxygen Production（m3/h） | 5 |
| Hydrogen Purity（V/V） | ≥99.99% |
| Oxygen Purity（V/V） | ≥92.5% |
| Operating load | 50%-100% |
| Working Pressure（MPa） | 1.5~3.0 |
| Hydrogen Moisture Content（g/m3） | ≤4 |
| Hydrogen Alkalinity（mg/m3） | ≤1 |
| Working Temperature（℃） | 85±5 |
| Cooling water flow（m3/h） | 1.9 |
| DC power consumption(kW·h/m3H2) | ≤4.3 |
| External dimension of electrolyzer L×W×H （mm） | 1355×850×780 |
| Electrolyzer Weight（kg） | 1500 |
| Alkali concentration | 30% KOH |
| Circulation quantity of alkali liquor（m3/h） | 0.5~0.6 |
| Koh consumption (normal operation)（kg/unit） | 65 |
Company Information
The purification equipments designed and produced by our company mainly includes the purification of electrolytic hydrogen and oxygen, and the gas purification of hydrogen-rich chemical by-products.
What's more, by electrolysis hydrogen and oxygen purification equipment, the content of impurities in the product gas after primary purification can be less than 1ppm;After the two-stage purification, the content of various impurities can be less than 0.1 PPM.
At the same time, we can also use ultra-low temperature adsorption or metal getter technology to reduce the content of impurities to 1ppb to meet various needs of users.
The gas processing capacity is 2 - 2000N m3/h, and the working pressure is 0.1MPa - 5.0MPa.
