Technical Specifications
|
P/N |
ZXD-40 |
ZXD-50 |
ZXD-60 |
|
Hydrogen Production（m3/h） |
50 |
60 |
65 |
|
Oxygen Production （m3/h） |
20 |
25 |
30 |
|
Hydrogen Purity（V/V） |
≥99.99% |
≥99.99% |
≥99.99% |
|
Oxygen Purity （V/V） |
≥92.5% |
≥92.5% |
≥92.5% |
|
Operating load |
50%-100% |
50%-100% |
50%-100% |
|
Working Pressure（MPa） |
1.5~2.6 |
1.5~2.0 |
1.5~2.0 |
|
Hydrogen Moisture Content（g/m3） |
≤4 |
≤4 |
≤4 |
|
Hydrogen Alkalinity（mg/m3） |
≤1 |
≤1 |
≤1 |
|
Working Temperature（℃） |
85±5 |
85±5 |
85±5 |
|
Cooling water flow （m3/h） |
6.6 |
8 |
9 |
|
DC power consumption (kW·h/m3H2) |
≤4.3 |
≤4.3 |
≤4.3 |
|
External dimension of electrolyzer L×W×H （mm） |
1660x1450x1580 |
2000x1450x1580 |
2170x1450x1580 |
|
Electrolyzer Weight（kg） |
6350 |
7100 |
7600 |
|
Alkali concentration |
30% KOH |
30% KOH |
30% KOH |
|
Circulation quantity of alkali liquor（m3/h） |
2.75~3.3 |
3.0~3.7 |
3.35~4.0 |
|
Koh consumption (normal operation)（kg/unit） |
430 |
470 |
520 |
About hydrogen generation equipment
The total system is automatically controlled, the hydrogen, oxygen are supplied under the required
pressure. Hydrogen generation equipment by water electrolysis is very suitable for site production
of hydrogen gas because it only needs water and electricity as materials, and used widely in many
industrial fields, include metallurgical, chemical, float glass, electrical power, oil & grease and nuclear
industry, aerospace and military fields, etc. zxdh2 hydrogen capacity of THE products is from 0.1Nm3/h
to 1000Nm3/h, the work pressure can reach to 50barg.
ZXDH2 technology(Professional team)
zxdh2 recognises that one size of product does not fit all applications. Our highly qualified team is
able to bring together a package to meet your needs.
● Rapid Response
Enables participation in primary and secondary grid balancing markets.
● Full Integration
Means that all necessary sub-systems are included as standard.
● Modular Structure
Allows flexibility of sizing using well proven technology and design.
● Dynamic Stack Clamping Technology
Allows variable operation and rapid stack exchange in the field.
● Hydrogen Generated
Is a purity suitable for fuel cell electric vehicles.
● Flexible Control System
With remote control and condition monitoring features.
● Highly Skilled & Experienced Team
From design, delivery and after sales support.
