H2 Purification / We're professional hydrogen generator
Inhouse product
-
LUB12 standard controll unit
$60.00
It will be a right choice to cooperate with us
Sales manager : Jessica
Email mailto : sales1@zxdh2.com
Skype : jessica01235483
Wechat : hu18030235311
Phone/Whatsapp: +86-18030235311
Tech Specification
|
P/N |
ZXD-20 |
ZXD-24 |
ZXD-30 |
|
Hydrogen Production（m3/h） |
20 |
24 |
40 |
|
Oxygen Production（m3/h） |
10 |
12 |
15 |
|
Hydrogen Purity（V/V） |
≥99.99% |
≥99.99% |
≥99.99% |
|
Oxygen Purity（V/V） |
≥92.5% |
≥92.5% |
≥92.5% |
|
Operating load |
50%-100% |
50%-100% |
50%-100% |
|
Working Pressure（MPa） |
1.5~3.0 |
1.5~2.6 |
1.5~2.6 |
|
Hydrogen Moisture Content（g/m3） |
≤4 |
≤4 |
≤4 |
|
Hydrogen Alkalinity（mg/m3） |
≤1 |
≤1 |
≤1 |
|
Working Temperature（℃） |
85±5 |
85±5 |
85±5 |
|
Cooling water flow（m3/h） |
3 |
3.6 |
4.2 |
|
DC power consumption(kW·h/m3H2) |
≤4.3 |
≤4.3 |
≤4.3 |
|
External dimension of electrolyzer L×W×H （mm） |
1680x1160x1400 |
1900x1160x1400 |
2180x1160x1400 |
|
Electrolyzer Weight（kg） |
3900 |
4300 |
4800 |
|
Alkali concentration |
30% KOH |
30% KOH |
30% KOH |
|
Circulation quantity of alkali liquor（m3/h） |
1.7~2.0 |
1.9~2.2 |
2.0~2.5 |
|
Koh consumption (normal operation)（kg/unit） |
260 |
ZXD-24 |
320 |
Main Features of the Product
●Ultra-pure gas:
Ultra-pure (99.999%) gas generation with continuous purity monitoring function can
extend the life of the equipment and save a lot of maintenance and replacement costs.
● Reliable reliability:
The system is equipped with an overvoltage protection device. If the hydrogen output
flow exceeds the maximum pressure, the generator will automatically shut down. It can
be restarted after turning off the power manually.
● Stable gas flow:
Continuous and stable gas output: The generator can be used continuously or intermittently,
and the gas produced is stable and high in purity.
●Exhaustive test:
Each unit has passed a comprehensive factory test, in line with national standards and beyond
the industry standards.
● On demand supply:
1.The delivery pressure is adjustable from 0 to 0.35 MPa
2.The maximum flow conveying range is from 0.018 m3/h to 50 m3 / h
3.The higher flow conveying range can meet your specific hydrogen requirements
4.Simple operation, easy maintenance: the hydrogen generator can be started by a button, and the
design is simple. The generator comes with a spare connector and O-ring for end user convenience.
● Automatic Water-feeding:
The float and the pump work together to achieve automatic water-feeding
