generating hydrogen gas
Inhouse product
-
LUB12 standard controll unit
$60.00
|CONTACT：SANDY|
Email: info@zxdh2.com || Skype: onlywnn_1
Whatsapp: +86-18020776786
| Quick Details |
|
P/N |
ZXD-10 |
|
Hydrogen Production（m3/h） |
10 |
|
Oxygen Production（m3/h） |
5 |
|
Hydrogen Purity（V/V） |
≥99.99% |
|
Oxygen Purity（V/V） |
≥92.5% |
|
Operating load |
50%-100% |
|
Working Pressure（MPa） |
1.5~3.0 |
|
Hydrogen Moisture Content（g/m3） |
≤4 |
|
Hydrogen Alkalinity（mg/m3） |
≤1 |
|
Working Temperature（℃） |
85±5 |
|
Cooling water flow（m3/h） |
1.9 |
|
DC power consumption(kW·h/m3H2) |
≤4.3 |
|
External dimension of electrolyzer L×W×H （mm） |
1355×850×780 |
|
Electrolyzer Weight（kg） |
1500 |
|
Alkali concentration |
30% KOH |
|
Circulation quantity of alkali liquor（m3/h） |
0.5~0.6 |
|
Koh consumption (normal operation)（kg/unit） |
65 |
| Product Characteristic |
The hydrogen production capacity of single equipment is up to 20Nm3/h-1500Nm3/h, and hydrogen production’s layout is achieved by station.
The exterior of all stainless steel equipment has been polished which makes it good-looking.
The electrolyzer adopts bipolar filter pressing structure, and the insulation of sealing gasket is strong.
The structure of gas-liquid processor, whose process is simple, is frame combined, making the installation, operation and maintenance easier.
The silicon rectifier is adopted to replace the original silicon controlled rectifier, which can reduce the harmonic interference to the power grid, effectively eliminating the high-order harmonic pollution to the power grid, and reducing the reactive power loss.
Controlled by highly automatic microcomputer, the system is able to do remote centralized management. Human-machine intelligent interface makes the operation easy, safe and reliable.
The purity of the hydrogen generated can reach to 99.99%, oxygen 99.2%
| about ZXD：After-sales Service Support |
Zhongxinda is committed to providing high quality products and equipment.
The hydrogen production engineering department is backed up with senior engineers, covering production, installation, commissioning, and other services.
It is a comprehensive after-sales service team with technical service strength.
Our after-sales service team not only ensures that each set of equipment can be delivered to users quickly with excellent performance during on-site installation and commissioning,
we also provide professional online technical questions and quick on-site service after equipment failure when the official production of the equipment is done.
| CONTACT：SANDY |
Email: info@zxdh2.com || Skype: onlywnn_1
Whatsapp: +86-18020776786
| Detailed Images |
