Hydrogen oxygen separator manufacturer
Inhouse product
-
LUB12 standard controll unit
$60.00
【CONTACT：SANDY】
Email: info@zxdh2.com || Skype: onlywnn_1
Whatsapp: +86-18020776786
TechSpecification
|
P/N |
ZXD-10 |
|
Hydrogen Production（m3/h） |
10 |
|
Oxygen Production（m3/h） |
5 |
|
Hydrogen Purity（V/V） |
≥99.99% |
|
Oxygen Purity（V/V） |
≥92.5% |
|
Operating load |
50%-100% |
|
Working Pressure（MPa） |
1.5~3.0 |
|
Hydrogen Moisture Content（g/m3） |
≤4 |
|
Hydrogen Alkalinity（mg/m3） |
≤1 |
|
Working Temperature（℃） |
85±5 |
|
Cooling water flow（m3/h） |
1.9 |
|
DC power consumption(kW·h/m3H2) |
≤4.3 |
|
External dimension of electrolyzer L×W×H （mm） |
1355×850×780 |
|
Electrolyzer Weight（kg） |
1500 |
|
Alkali concentration |
30% KOH |
|
Circulation quantity of alkali liquor（m3/h） |
0.5~0.6 |
|
Koh consumption (normal operation)（kg/unit） |
65 |
Product Characteristic
The structure of gas-liquid processor, whose process is simple,
is frame combined, making the installation, operation and maintenance easier.
The silicon rectifier is adopted to replace the original silicon controlled rectifier,
which can reduce the harmonic interference to the power grid, effectively
eliminating the high-order harmonic pollution to the power grid, and reducing the reactive power loss.
Controlled by highly automatic microcomputer, the system is able to do
remote centralized management. Human-machine intelligent
interface makes the operation easy, safe and reliable.
The purity of the hydrogen generated can reach to 99.99%, oxygen 99.2%
Precautions for transportation and storage of hydrogen production equipment
Hydrogen production equipment shall be stored in a cool and ventilated warehouse
with obvious "no fireworks" sign. Keep out of direct sunlight. Hydrogen should be
stored separately from oxygen explosives, poisons, radioactive materials, organic
peroxide and other combustible materials. Warehouse lighting, ventilation
and other facilities shall be explosion-proof.
What is the standard of hydrogen production equipment?
Service life, failure rate, hydrogen quality, cost performance
and after-sales service of hydrogen production equipment.
Is hydrogen production equipment safe?
The hydrogen production equipment is relatively safe with correct
and standardized use. When the hydrogen production equipment is
not in operation, a small amount of gas will be stored in the equipment,
and the hydrogen density is very low. A large amount of gas will be stored
in high-pressure cylinders or hydrogen storage tanks. Under the condition
of forced circulation of electrolyte and direct current to the electrolyzer,
hydrogen and oxygen are generated in the electrolyzer. After gas-liquid
separation in the separator, the produced hydrogen and oxygen will be
continuously sent out of the system. In addition, the additional flame arrester,
leakage detection and ventilation in the system provide additional system
safety measures, and hydrogen leakage will not occur.
