Control cabinet of hydrogen production equipment
Inhouse product
-
LUB12 standard controll unit
$60.00
Control cabinet of hydrogen production equipment
Contact us
Sales Manager: Jessica
Email: sales1@zxdh2.com | Skype: jessica01235483
WhatsApp: +86-18030235311 | Wechat: hu18030235311
Product Parameters
|
P/N
|
ZXD-16
|
|
Hydrogen Production（m3/h）
|
16
|
|
Oxygen Production（m3/h）
|
8
|
|
Hydrogen Purity（V/V）
|
≥99.8%
|
|
Oxygen Purity （V/V）
|
≥92.5%
|
|
Operating load
|
50%~100%
|
|
Working Pressure（MPa）
|
1.5~2.0
|
|
Hydrogen Moisture Content （g/m3）
|
≤4
|
|
Hydrogen Alkalinity（mg/m3）
|
≤1
|
|
Working Temperature（℃）
|
85±5
|
|
Cooling water flow（m3/h）
|
2.6
|
|
DC power consumption
(kW·h/m3H2) |
≤4.3
|
|
External dimension of electrolyzer
L×W×H （mm） |
1515×1160×1400
|
|
Electrolyzer Weight （kg）
|
3600
|
|
Alkali concentration
|
30% KOH
|
|
Circulation quantity of alkali liquor
（m3/h） |
1.55~1.85
|
|
KOH consumption (normal operation（kg/unit）
|
240
|
Product description
An electrolytic cell consists of 68 cells with maximum DC voltage. 136v, rated DC current 740A, ensure the H2 gas flow of 20ncmh and O2 gas flow of 10ncmh; (detailed parameters should be confirmed in the process of detailed engineering design.)
Chemical KOH (25% to 30%) is used as an additive in the electrolyte to increase conductivity, but does not consume chemicals during normal operation, so there is no need to supplement the electrolyte after the first start-up.
The patented special technology can design the hydrogen generator and make it operate under the pressure of 1.50 MPa (g) without using any gas compressor.
Therefore, if the customer needs more pressure and has to use a hydrogen compressor to increase the pressure, the gas output of the generator will be pressurized to 1.50mpa (g), so as to improve the reliability of the generator and save the capital cost for the customer.
| green hydrogen electrolysis | green hydrogen electrolyzer |
| green hydrogen uses | water electrolysis to produce hydrogen |
| solar hydrogen production | energy to produce hydrogen |
| solar electrolysis for hydrogen production | energy from hydrogen |
| hydrogen production using solar energy | electrolyzer water |
| china green hydrogen | electrolysis of water for hydrogen production |
| china hydrogen production | companies producing hydrogen |
| hydrogen is produced by | industrial electrolysis of water |
| hydrogen production news | electrolyser cell |
| green hydrogen system | green energy hydrogen |
| make hydrogen gas | hydrogen manufacture |
| hydrogen production water electrolysis | electrolyzer producers |
| fuel hydrogen | electrolyzer for hydrogen production |
| make hydrogen from water | electrolysis for hydrogen |
| green hydrogen price | green hydrogen storage |
Xiamen Zhongxinda Hydrogen Energy Technology Co., Ltd
www.zxdh2.com
Company Information
We have a professional after-sales service team for hydrogen generation system with rich experience in hydrogen machine maintenance.According to the running state and environment of hydrogen production machine , we will help you optimize and upgrade the system, design plans suitable for the operation of the machine, improve the monitoring and detection for DCS and PLC, enhance the running safety and using cycle of hydrogen production equipment, so that reduce system failure caused by peripheral equipment (hydrogen compressor, dryer, PLC controller, etc.) and equipment failure or accident caused by personnel operation mistakes.
In view of the system shutdown caused by the fault of individual components for most users (such as system pressure imbalance and inaccurate measurement of the analyzer caused by the fault of pressure transmitter and ), we have stable detection methods and equipment maintenance plans for hydrogen production machine.
